A PVS-31 field strip is one of the genuinely useful features of this housing, and one of the most misunderstood. Legacy binoculars in this pattern were designed to be serviced at depot level: the lenses were not meant to come off in the field, and a failed tube meant sending the whole goggle away. Our PVS-31 was designed the other way round, with lenses and tubes that come out for maintenance and troubleshooting without a depot. What follows is what that actually buys you, what it does not, and the maintenance routine that keeps the goggle out of a shop.
What comes off, and how
The objective and eyepiece assemblies are held by retaining rings that release with the correct spanner. The disassembly tool set for this pattern is the same one our production line uses, which matters because improvised tools mark ring slots and damage threads. With the rings off, the lens assembly lifts clear and the tube is accessible.
That access enables four things without a bench:
- Swapping a scratched objective for a new one.
- Fitting a sacrificial lens or a different diopter lens.
- Pulling a suspect tube to read its serial and data sheet, or swapping in a known-good tube to isolate a fault.
- Cleaning the inner face of a lens after a fogging event.
PVS-31 and PNVG-18 disassembly tool set
What a PVS-31 field strip does not mean
Field-strippable does not mean purge-free. The pod is sealed to IP67 as standard, with IP68 available on request, and that seal is holding dry nitrogen. Ingress protection ratings are defined by the international standard IEC 60529, and the rating describes the sealed state, not the state after you have opened it. Open a pod and the next sharp temperature change will fog the internal glass.
The workflow that follows from this is simple: strip in the field to diagnose and to get the goggle working, then purge at the first opportunity. If you intend to strip regularly, a purge setup belongs on your equipment list rather than your wish list.
Field-strippable also does not mean collimation-free. On a binocular the two tubes are aligned so that each eye sees the same point in space. Pulling a tube and refitting it usually lands close, and close is a headache after an hour of use. Our line collimates on dedicated bench equipment; Hoffman Engineering manufactures the ANV-126A that is the industry reference for collimation, gain and diopter measurement. If you have swapped a tube, have the goggle checked before you rely on it.
Why the housing is built this way
Quick disassembly is not a bolt-on feature. It falls out of a weight and resolution decision.
The PVS-31 delivers a system resolution up to 72 line pairs per millimetre and weighs 450 grams or less with tubes and without a battery. To reach both numbers the optical train is short and the lens elements are held with minimal hardware. That same minimal hardware is what makes the lenses removable. The rest of the specification follows the same logic: a pod pivot angle of at least 130 degrees, an operating range of minus 40 to plus 60 degrees Celsius, and a matte black fibre-reinforced nylon shell.
PVS-31 housing kit with lenses
The maintenance routine that keeps it out of the shop
Fit a sacrificial lens to the objective. It takes the brush scratches and the residue that would otherwise land on the objective element. Replace the sacrificial lens, not the objective.
PVS-31 objective sacrificial lens
Set the manual gain default once. The housing lets you personalise the default brightness for manual gain tubes, so the goggle powers up at your preferred level rather than at maximum. Set it and leave it.
Let the sleep function work. After roughly 100 seconds without movement the tubes power down and wake on motion. This protects the phosphor screens from a static burn and is a large part of why the goggle runs 15 hours or more on a single AA and 50 hours or more on an external pack.
Do not defeat flip-up shutoff for storage. Flip up cuts power, flip down restores it. A goggle stored flipped down with a cell installed wakes every time the case is knocked.
Purge annually, and after any pod opening. This is the one item that genuinely needs equipment.
A sequence that avoids the common mistakes
Order matters more than technique here. Work in this sequence and most of the ways a strip goes wrong are designed out.
- Work clean and work dry. A wiped bench, good light and no moving air. Dust that lands on an inner lens face during a two-minute job is permanent.
- Photograph before you touch anything. Ring orientation, cable routing and shim positions are obvious now and not obvious in an hour.
- Loosen with the correct spanner, fully engaged. A spanner that is only half in the slot will slip and mark the ring, and a marked ring is harder to grip next time.
- Keep left and right separate. Tubes and lens assemblies are not interchangeable once a goggle has been collimated as a pair. Two labelled trays cost nothing.
- Inspect the tube faceplate before refitting. A fingerprint here is invisible until the pod is closed and powered, at which point you have to open it again and repeat the purge.
- Dry-fit and power up before sealing. Confirm you have an image in both channels before you commit to a purge cycle.
- Purge, then check. Fill, seal, leak-check, and only then call the job done.
The one thing people over-tighten
Retaining rings need to be firm, not tight. They are holding a lens assembly against a seat, not resisting a load, and the threads are fine.
Over-tightening does two things, both bad. It deforms the seat slightly, which can shift the optical alignment you are trying to preserve. And it makes the next removal harder, which encourages an improvised tool, which marks the ring. Snug the ring until it stops moving easily and leave it there.
If a ring will not seat without force, something is cross-threaded or a component is not sitting flat. Back it off and look rather than pushing through.
Storage and transport, which cause more damage than use
Most of the damage we see on this housing does not happen in the field. It happens in a bag.
Leave a cell in the housing over a long storage period and you risk a leak that destroys the contact assembly. Store the goggle flipped down with power available and it wakes every time the case is knocked, quietly consuming the battery. Pack it without lens protection and the objective takes scratches from whatever else is in the bag.
The fixes are trivial and rarely applied: remove the cell, stow flipped up, fit the caps and protective lenses, and keep the goggle in a hard case rather than loose. The relevant night vision spare parts are inexpensive next to an objective replacement.
When the field strip finds a bad tube
If you pull a tube and the fault follows it into the other pod, you have your answer. What happens next depends on the paperwork. A tube with a serial number and a measured figure of merit can be assessed against its own sheet on a tube tester, and the result is a factual pass or fail. A tube with neither is a guess.
One thing not to do: run a binocular with one good tube and one marginal tube. The mismatch in gain and screen brightness is more fatiguing than using a monocular, and users routinely misattribute the resulting eye strain to the housing. If you need a replacement, buy from the same grade band and have the pair matched. The current inventory across grades sits in our image intensifier tube listings with measured values attached to each serial.
What the tools actually cost against what they save
The spanner set is the cheapest insurance in this whole subject. A marked retaining ring is cosmetic; a damaged thread is a housing repair. The tool set costs a small fraction of a single objective assembly, and it is the same pattern used on the production line rather than a generic approximation.
The diopter test device sits in a different category. It is worth owning if you swap tubes or lenses more than occasionally, and hard to justify for a single goggle that is stripped once a year. Borrowing bench time is often the better answer for an individual owner.
Nitrogen purge equipment is the genuine capital item, and for most owners the right decision is to build a relationship with a shop rather than a purge station.
A realistic view of who should strip and who should not
Field stripping is appropriate if you have the correct spanners, a clean working surface, and either purge access or a plan to get the goggle purged soon. It is appropriate for diagnosis almost regardless of equipment, because identifying which pod carries the fault shortens any subsequent repair.
It is not appropriate as a routine cleaning habit. Every pod opening is a purge cycle, and pods that are opened casually accumulate seal wear and dust that no amount of cleaning removes. Strip when you have a reason, not out of curiosity.
Used within those limits, quick-disassembly lenses turn a class of failure that used to mean a depot visit into a fifteen-minute bench job with a follow-up purge, which is exactly what the design was for.
Frequently Asked Questions
What does a PVS-31 field strip actually let me do?
Remove the objective and eyepiece assemblies with the correct spanners, which gives access to the tubes. That lets you swap a damaged lens, fit a sacrificial or diopter lens, pull a tube to read its data sheet, or clean the inner face of a lens after fogging, all without sending the goggle to a depot.
Do I need to purge the pods after a field strip?
Yes, if you opened a pod. The pods are sealed and hold dry nitrogen. Once humid air is inside, the goggle will fog at the next sharp temperature change. Strip in the field to diagnose and get running, then have the unit dried, refilled and leak-checked at the first opportunity.
Will removing and refitting a tube throw off collimation?
Usually it lands close, and close is not good enough for extended use. The two tubes must be aligned so both eyes see the same point, and a small error produces fatigue rather than an obviously double image. Have the goggle checked on bench equipment after any tube swap.
Can I run the goggle with one good tube and one weaker tube?
You can, but it is more fatiguing than using a monocular. Differences in gain and screen brightness between the two eyes are what cause the strain, and users often blame the housing instead. Replace within the same grade band and have the pair matched.
How often should the goggle be purged if I never open it?
Annually is a sensible interval for a device in regular use, and immediately after any event that could have compromised a seal. A goggle that fogs internally is telling you the interval was too long or a seal has failed.
